LOOPLAX SICL
(SCOURING MACHINE 'BOIL OFF') |
|
|
|
|
Features
• LOOPLAX is a system where the fabric is hung on the rotating loop installed inside the fluid to enable long-time stay and transmission under no tension. This device has excellent desizing, scouring and relax effects.
• Quality of Boil off LOOPLAX, which is designed and manufactured for stabilized transmission of general fabric and broad fabric (fabric width 3.6m, 140 inch) has received quality certification.
• Scouring and relax of black window covering curtains, broad curtains, blinders, fabric wallpapers and super-fibers. |
|
|
|
|
|
Model |
SICL 100 |
|
Cloth length (km) |
250~450 |
Liquid Volume (liters) |
1,800 |
Operate Speed (m/min) |
10~40 |
Operate Temperature () |
80~95 |
Reaction Time (min) |
10~30 |
Electric Power (kW) |
125 |
Installed width (mm) |
5,000 |
Height (mm) |
60,000 |
LOOPLAX fabric Width ; 3.6m(140inch) |
|
|
|
|
|
|
