YARN DYEING MACHINE SIDY |
 |
|
 |
|
Features
• Overall processes including indirect cooling, moisture separation and humidifying are optimized and automatically operated by a program.
• Indirect cooling used to reuse collected coolant.
• High durability of each system enables easier maintenance.
• Drying cone, beam, loose, top, tow type dyed cottons T/C, PET, wool and acetate. |
|
|
| |
  |
|
| Model |
SIDY 50 |
SIDY 100 |
SIDY 200 |
SIDY 400 |
| Loading Capacity (kg) |
50 |
100 |
200 |
400 |
| Liquid (liters) |
250~365 |
500~700 |
1,000~1,400 |
2,000~2,800 |
| Electric Power (kW) |
13.6 |
24.6 |
33 |
58.7 |
| Installed width (mm) |
1,500 |
1,500 |
2,000 |
3,000 |
| Length (mm) |
3,700 |
4,000 |
4,300 |
5,500 |
| Height (mm) |
5,700 |
5,700 |
5,700 |
6,000 |
| Max. operating temperature |
140℃ |
|
|
|
| Heating rate (Saturate Steam 0.7㎫) |
Approx. 30min (from20℃ to140℃) |
|
|
| Cooling rate (Cooling Water 0.1㎫, 15℃) |
Approx. 20min (fom140℃ to 80℃) |
|
|
|
|
| |
 |
|
|
